DSHG06-3C4-D24-N1-51, Yuken Direction Control Valve

Name: DSHG06-3C4-D24-N1-51, Yuken Direction Control Valve Model: DSHG06-3C4-D24-N1-51 Make:  YUKEN INDIA LTMITED These valves are composed of a solenoid operated pilot valve and a pilot operated slave valve. High Pressure High Flow- High pressure [31.5 MPa (4570 PSI)] along which high flow means compact system design. Lower Pressure Drop- System energy saving increased as pressure drop of each valve has been greatly reduced.

• Weight:  12.7 KG
• Working Pressure(BAR): 315
• Flow(LPM):  500
• Coil Voltage: D24

Solenoid Controlled Pilot Operated Directional Valves These valves are composed of a solenoid operated pilot valves and a pilot operated slave valve. When a solenoid is energized the pilot valve directs the flow to move the spool of the slave valve, thus changing the direction of flow in the hydraulic circuit.

• High Pressure High Flow

High pressure [315 Kgf/cm2] along with high flow means compact system design.

• Lower pressure Drop

System energy saving increased as pressure drop of each valve has greatly reduced.

Specifications



• Maximum flow indicates a ceiling flow. As the ceiling flow depends on the type of spool and operating condition.
• Pilot pressure of internal pilot drain models must always exceed tank line back pressure by a minimum required pilot pressure.
