Hydraulic Valves

Sandwich Design Valves

We have defferent type of sandwitch design valves in CETOP 3 and CETOP 5 sizes, which can also be customized according to the customer requirements.The different type of valves include Pressure Relief Valves, Pressure Reducing Valves, Flow Control valves, Load Holding Valves, Break valves Etc.All the valves are 100% tested before delivery and the valves can be supplied with preset pressure setting on customer request.
Some of the valves developed by us are: -

CETOP 3
Pressure Relief Valves	350 Bar	40 LPM
Pressure Reducing Valves	350 Bar	40 LPM
Pilot Check Valves	350 Bar	40 LPM
Flow Control Valves	350 Bar	40 LPM
Flow Control Cum Check Valves	350 Bar	40 LPM
Break Valves	350 Bar	40 LPM
Conter balance Valves	350 Bar	40 LPM
CETOP 5
Pressure Relief Valves	350 Bar	70 LPM
Pressure Reducing Valves	350 Bar	70 LPM
Pilot Check Valves	350 Bar	70 LPM
Flow Control Valves	350 Bar	70 LPM
Flow Control Cum Check Valves	350 Bar	70 LPM
Break Valves	350 Bar	70 LPM
Conter balance Valves	350 Bar	70 LPM

Customized Circuits

We have capability to design and manufacture hydraulic valves as per the application requirement.Our team of highly professional hydraulic engineers work with the customers right from the design stage and develop efficient solutions, which matches the customer requirements.
Some of the valves developed by us are: -

Lift Lowring Valves	Dump Valves	Back Pressure Valves
Regeneration Circuits	Logic Valves Circuits	Exhaust Valve
Decompression Circuits	Conter Balancing Valves

Inline Design Valves

These Valves are designed to be used on line and can be easily fitted in a Hydraulic System with the help of tubing and fittings.
Some of the valves developed by us are: -

Throttle Cum Check Valve	350 Bar	150 LPM
Direct Pressure Relief Valves	350 Bar	400 LPM
Sequence Valves	350 Bar	100 LPM
Single Counter Balance Valves	350 Bar	120 LPM
Dual Counter Balance Valves	350 Bar	120 LPM
Pilot Check Valves	350 Bar	120 LPM
